Power Steering Cylinders--How Does One Work?

   / Power Steering Cylinders--How Does One Work?
  • Thread Starter
#11
   / Power Steering Cylinders--How Does One Work? #12
Not only is the difference in the two sides small enough to not be noticeable.....(81% as you calculate)

You are forgetting the most important reason.....

Your steering wheel that is connected to the orbital valve......its like one big flow control device. Meaning you have plenty of flow.......the steering wheel controls how fast the wheels turn by how fast you turn the wheel.

for example....your 18mm rod and 42mm bore cylinder.......probably paired with about 3gpm flow for your steering........that cylinder can extend at ~5.5" per second.....or retract at 6.5" per second.

So unless you are trying to spin the wheels to make the cylinder move much faster than that.......you have ample flow.

The steering wheel controls the speed.

Similar to my front loader......or any controls on my backhoe. By feathering the valve........I can make the cylinders move as fast as the pump will allow.......or as slow as I want. I can make my loader raise (extend the cylinder) FASTER than lowering it simply by feathering the valve (controlling the flow).....which is all the orbital valve is doing.

   / Power Steering Cylinders--How Does One Work? #13
My steering was a little fast when I first did it, but I quickly got used to it. Just takes a little bit of seat time.

   / Power Steering Cylinders--How Does One Work? #14
I would still like to know how that orbitrol works. With a hydraulic pump working and not.

   / Power Steering Cylinders--How Does One Work? #15
While on the subject of cylinders I have one that I can not use for a Kioti DK 40, they use 2 cylinders, bought as new surplus in error. Offers? trade?

   / Power Steering Cylinders--How Does One Work?
  • Thread Starter
#16
I would still like to know how that orbitrol works. With a hydraulic pump working and not.

orbitrol - Yahoo Video Search Results

This is a schematic representation of how the orbitrol works. In the video the comment is made that the gerotor (which the steering wheel actuates) acts as a pump or a motor. Lose hydraulic pressure and the steering wheel rotation pumps fluid to the steering cylinders. It's a safety feature in case of loss of pressure while traveling at relatively high speed.

   / Power Steering Cylinders--How Does One Work? #17
Automotive power steering gears have a small torsion bar hooked to the input shaft from the steering wheel. As torque is applied to the steering wheel the torsion bar twists, allowing a small amount of relative movement between the two parts of the valve. This opens the ports to allow flow to the cylinder. When the wheel is released the torsion bar centers the valve parts, shutting off the flow.

I suspect the orbitrol valve works the same way, but I've never had one apart.

   / Power Steering Cylinders--How Does One Work? #18
The first tractor we bought with hydrostatic power steering was not a balanced double acting cylinder and you needed to keep turning slowly in one direction to keep it going straight. Then I started my engineering career with a combine manufacturer and we had the same problem - too cheap to buy the right cylinder for the job but we were selling everything we could get out the door. With a market downturn, we needed to take customers seriously. 2 single acting cylinders, one for right, one for left, turned out to be cheaper than a single balanced cylinder with the proper capacity and having plenty of room, we went in that direction. A good HMU (hand metering unit) will not give much drift.

   / Power Steering Cylinders--How Does One Work? #19
I added hydraulic steering to my kubota. It's just a hydraulic cylinder bolted to where the arm used to be for the manual steering. I added a steering column from a deere 318.

Steering is effortless now with the blower up on dry asphault. Best thing I did to my tractor.












Its been over a year now. Any updates? How many hours have you put on the unit?

I have ab8200 with a exploded steering box and going full hydro seams to be the best thing. Mine has a loader on it also.

   / Power Steering Cylinders--How Does One Work? #20
Since this old thread has recently be resurrected... I'd just like to say that when I first bought my Mahindra 1626 HST the single DA steering cylinder really messed with my OCD. On at least a couple of occasions I popped the center cap on the steering wheel to "properly" align the logo when the front wheels were straight. It's the only part of the dealer prep I took issue with. LOL! Much to my chagrin... the **** thing would be off center the next time I focused on it's orientation. It made me question whether I had really centered it or not! Finally I said "screw it" and decided not to worry about it... only to see it oriented correctly a day or two later.

I did learn that it was dynamic before finding this thread. But reading this thread really helped me understand it more fully.
