Anyone have a wiring diagram for an XR3135H? The machine comes with a couple of pigtails but they show hot whether or not the "worklight" (pre-installed) switch is engaged or not. There is a stock work light facing rear that can be turned on by a switch on the actual lamp housing. It has nothing to do with the dash switch. This is an open station that I found a lot of good hardware (LEDs) on Amazon for but I want to get it right. I don't even have the operators manual for this machine yet. It was a very rare find on my dealers lot with a little over an hour on it when I brought it home.
XR3135H
- Thread starter Spin88
- Start date
- Views: 2995
George2615
Super Member
Welcome to TBN.................
Congrats on your new tractor. The rule here is to post pictures or it didn't happen. We like pics.
Wiring diagram will not be in the owners manual but is in the service manual which would have to be ordered through your dealer. I have not read any posts from other 3135 owners who bought one yet.
Congrats on your new tractor. The rule here is to post pictures or it didn't happen. We like pics.
Wiring diagram will not be in the owners manual but is in the service manual which would have to be ordered through your dealer. I have not read any posts from other 3135 owners who bought one yet.
Yeah, I know the operators manual will have limited information. I was just painting the picture of not having anything informative outside of the dealer and pre-buy research. I love this machine so far. I appreciate your response. Here are those pix:
