LTX 1050 deck belt problems

[mrrockyroad]

I have an ltx 1050 with 26 hours on it.
So far, this mower seems to have too many problems.

The current problem involves trying to change the deck belt, which unfortunately has already broken.
I ordered the belt and it came in, so removed the deck with no problem.

This deck has the pulleys with the spring at rear of the deck.
And a fairly complex belt routing.

The spring that connects to the pulley is in the path of the belt.
It seem obvious that the belt needs to go under the spring or it would rub.
But we cannot figure out how to get the belt under the spring.
I have watched a bunch of videos, but none show the configuration of the spring or the pulleys like on my mower deck.
(Pulleys on the back with the spring running front/back)

I figure that there must be a fairly simple way to do this, but I am just not seeing it.
And I could use a bit of help!
Thanks.



[rcbe]

have you followed the step by step instructions (with diagrams) in your owners manual? They seem to be quite complete... Look in section 7, Pp 27.



[mrrockyroad]

have you followed the step by step instructions (with diagrams) in your owners manual? They seem to be quite complete... Look in section 7, Pp 27.

Thanks

Unfortunately the mower came with the owner's manual for a 1040, not a 1050.

I wish that I could follow the step by step instructions!



[Bob_Bainbridge]

Thanks

Unfortunately the mower came with the owner's manual for a 1040, not a 1050.

I wish that I could follow the step by step instructions!

Here is a URL where you can download the User Manual which has pictures of the belt routing & instructions for belt replacement. The idler arm has to be loosened to slip the belt under it.

http://www.cubcadet.info/Manuels/2005/Tracteurs/LT1042-LT1045-LT1046-LT1050-Owner.pdf

Bob B.



[mrrockyroad]

Here is a URL where you can download the User Manual which has pictures of the belt routing & instructions for belt replacement. The idler arm has to be loosened to slip the belt under it.

http://www.cubcadet.info/Manuels/2005/Tracteurs/LT1042-LT1045-LT1046-LT1050-Owner.pdf

Bob B.

Thank you!



[radioman]

I been working on a lt1050 for a client- took deck off to inspect transmission issue. I think whats your issue is that the spring is your biggest hurdle. just follow the routing diagram that is actually on a sticker on the deck. Don't put belt on the pto clutch yet , once you get belt lined up you can hook the spring on the bolt and tensioner pulleys and then push on the tensioner to make a slack so you can start slipping the belt onto the pto clutch pulley and walk it the rest of the way to put belt onto the pto clutch pulley.



[Dr Dave]

Be sure to keep the, pivot lubed for the deck belt tensioner.

Dave



[bullbreaker]

Wow been reading this thread and not compareing or bashing brands but , I didn't change belts (primary-mtr 2 pulley) or secondary (deck) on my JD235 till after 9 and one half years and over 450 hrs. Think I could go another ten years with scheduled maintenance. Also mine was $5200 OTD almost ten years ago.
To the OP hope you get bugs straightened out of it !

Boone



[rcbe]

Wow been reading this thread and not compareing or bashing brands but , I didn't change belts (primary-mtr 2 pulley) or secondary (deck) on my JD235 till after 9 and one half years and over 450 hrs. Think I could go another ten years with scheduled maintenance. Also mine was $5200 OTD almost ten years ago.
To the OP hope you get bugs straightened out of it !

Boone

and I have CC machines with about same accumulated hours/yrs still running original belts. yer point? Oh, BTW... I didn't fork out $5k+ either.



[bullbreaker]

and I have CC machines with about same accumulated hours/yrs still running original belts. yer point? Oh, BTW... I didn't fork out $5k+ either.

Believe or not I thought / expected someone to respond to my post like you have while I was posting it. Might want to read my first post again slowly. Wasn't trying to make a point just did not expect belt problem at 26 hours, but then again that's main reason I enjoy TBN (to learn). Like I said I wasn't brand bashing either . Even wished OP well on repair of his "CC".

BTW : Those $ 5K + have been some of the best spent money I have spent since purchaseing my Kubota.

Boone
